ECONEXT® upper roof extension black plastic Ø 80/125 L500 PP flue pipe

Are you looking for brochures, manuals or videos of this product?

Flue gas and air supply pipe diameter:	80/125 mm
Length:	500 mm
Wall thickness inner pipe:	2 mm
Working length:	450 mm
Colour:	Black
Dry (non-condensing):	No
Material inner pipe:	Plastic
Material outer pipe:	Plastic
Material sealing:	Ethylene-propylene diene monomer rubber (EPDM)
Max. medium temperature (continuous):	120 °C
Negative (negative pressure):	No
Number of lips:	2
Outer pipe-outer pipe connection:	Other
Position of lips:	Straight
Positive (overpressure):	Yes
Production method for inner pipe:	Seamless
Production method for outer pipe:	Seamless
Quality class inner pipe:	Polypropylene (PP)
RAL-number:	9005
Surface protection outer pipe:	Untreated
Surface treatment outer pipe:	Untreated
Wet (condensing):	Yes
With clamping strip:	No
With lip ring:	Yes
With pull-out protection:	No

Art.nr.	Ø mm	RAL	Length (mm)	b	3	c
AJDWAAB01	60/100	9005	500	1	54	899
AJDWAAE01	60/100	8023	500	1	54	899
BJDWAAB01	80/125	9005	500	1	54	899
BJDWAAE01	80/125	8023	500	1	54	899

Suitable for
