CoxHYBRID® Connection pipe PP Ø 60 + cover plate-to reline CFS/Optifor
CoxHYBRID® Connection pipe PP Ø 60 + cover plate-to reline CFS/Optifor
Are you looking for brochures, manuals or videos of this product?
| Article number: | WANYAA000 |
|---|---|
| Packaging dimensions: | 550 x 255 x 183 mm |
| Quantity per pack: | 1 stuks |
| Number of units: | 1 stuks |
| Minimum order quantity: | 1 stuks |
| GTIN: | 08711939266291 |
| Gross weight: | 1,247 kg |
| Net weight: | 0,713 kg |
| Diameter connection 1: | Other |
|---|---|
| Diameter connection 2: | Other |
| Length of connection 1: | 500 mm |
| Wall thickness inner pipe: | 1.8 mm |
| Working length connection 1: | 482 mm |
| Dry (non-condensing): | No |
| Material inner pipe: | Plastic |
| Material outer pipe: | Aluminium |
| Max. medium temperature (continuous): | 120 °C |
| Negative (negative pressure): | No |
| Outer pipe-outer pipe connection: | Sleeve with seal |
| Positive (overpressure): | Yes |
| Production method for inner pipe: | Seamless |
| Production method for outer pipe: | Other |
| Quality class inner pipe: | Polypropylene (PP) |
| Surface protection outer pipe: | Hot-dip galvanized |
| Surface treatment outer pipe: | Untreated |
| Wet (condensing): | Yes |
| With bottom support: | No |
| With clamping strip: | No |
| With inspection opening and cover: | No |
| With lip ring: | No |
| With measuring points: | No |
CoxHYBRID® Connection pipe PP Ø 60 + cover plate-to reline CFS/Optifor
Available in 1 alternatives
| Art.nr. | Ø mm | b | 3 | c |
|---|---|---|---|---|
| WANYAA000 | 60 | 1 | 48 | 724 |
