CoxDry® Heat Recovery extension pipe below roof L 250 Ø 150
CoxDry® Heat Recovery extension pipe below roof L 250 Ø 150
Are you looking for brochures, manuals or videos of this product?
| Article number: | 224231 |
|---|---|
| Packaging dimensions: | 600 x 400 x 275 mm |
| Quantity per pack: | 6 stuks |
| Number of units: | 1 stuks |
| Minimum order quantity: | 6 stuks |
| GTIN: | 08711939014144 |
| Gross weight: | 0,63 kg |
| Net weight: | 0,51 kg |
| Insulation thickness: | 10.5 mm |
|---|---|
| Length: | 250 mm |
| Nominal duct diameter: | 150 mm |
| Anti-bacterial treatment: | No |
| Antistatic version: | No |
| Connection 1: | Insert end |
| Connection 2: | Other |
| Embeddable in concrete: | Yes |
| Inner surface protection: | Untreated |
| Material duct: | Steel |
| Material insulation: | Expanded polystyrene (EPS) |
| Model: | Internally insulated duct |
| Outer surface protection: | Hot-dip galvanized |
| Perforated inner wall: | No |
| Production method: | Other |
| Type approval according to BBR/EKS: | No |
| Wall thickness duct: | 14 mm |
| With push-on clamp: | No |
| With push-on profile: | No |
CoxDry® Heat Recovery extension pipe below roof L 250 Ø 150
Available in 2 alternatives
